Ring Terminals
Insulated electrolytic copper ring terminals - 35 sizes, 1000 pcs/bag.
Ring Terminals from WAHSURE are pressed from high-conductivity electrolytic copper tube and tin-plated, so the connection stays low-resistance and corrosion-free for years. The ring tongue design slides over the stud and is held by the fastener - which is exactly why these terminals are specified in high-vibration applications where a loosening connection is not an option.
The brazed seam protects the barrel from splitting during crimping, and the funnel-entry barrel guides the wire in cleanly for a full-depth crimp every time. The colored nylon insulation - red, blue, yellow and black - doubles as an at-a-glance wire-size code, and the insulation grip sleeve takes the strain off the crimp joint.
The RV series covers 35 sizes, packed 1000 pieces per bag. For automotive, industrial and general wiring jobs, this one line item covers most of what a service van or assembly bench needs.
Key Features
- High-conductivity electrolytic copper, tin-plated finish
- Ring tongue holds secure under vibration
- Brazed seam resists barrel splitting during crimping
- Funnel entry barrel and insulation grip sleeve
- Color-coded insulation: red, blue, yellow, black
- 35 sizes in the RV series; 1000 pcs/bag
Applications
Automotive harnesses, industrial panels, appliances and general wiring where a secure, vibration-proof stud connection is required.
Specifications
| ITEM NO | Dwire Range | φD | H | F | B | φd2 | L | Color | A | |
|---|---|---|---|---|---|---|---|---|---|---|
| AWG/MCM | mm2 | |||||||||
| RV1.25-3S | 22-16 | 0.5-1.5 | 4.3 | 10 | 4.3 | 5.7 | 3.2 | 17.8 | Red | 19 |
| RV1.25-3.5S | 4.3 | 5.7 | 3.7 | 17.8 | ||||||
| RV1.25-3.5M | 6.3 | 6.6 | 3.7 | 20.1 | ||||||
| RV1.25-3.5L | 7 | 8 | 3.7 | 21.5 | ||||||
| RV1.25-4S | 6.3 | 6.6 | 4.3 | 20.1 | ||||||
| RV1.25-4L | 7 | 8 | 4.3 | 21.5 | ||||||
| RV1.25-5 | 7 | 8 | 5.3 | 21.5 | ||||||
| RV1.25-6 | 11.1 | 11.6 | 6.5 | 27.5 | ||||||
| RV1.25-8 | 11.1 | 11.6 | 8.4 | 27.5 | ||||||
| RV1.25-10 | 13.9 | 13.6 | 10.5 | 31.6 | ||||||
| RV2-3 | 16-14 | 1.5-2.5 | 4.9 | 10 | 4.3 | 6.6 | 3.2 | 17.8 | Blue | 27 |
| RV2-3.5S | 4.3 | 6.6 | 3.7 | 17.8 | ||||||
| RV2-3.5M | 7 | 6.6 | 3.7 | 21 | ||||||
| RV2-3.5L | 7.8 | 8.5 | 3.7 | 22.5 | ||||||
| RV2-4S | 7 | 6.6 | 4.3 | 21 | ||||||
| RV2-4L | 7.8 | 8.5 | 4.3 | 22.5 | ||||||
| RV2-5S | 7.8 | 8.5 | 5.3 | 22.5 | ||||||
| RV2-5L | 7.3 | 9.5 | 5.3 | 22.5 | ||||||
| RV2-6 | 11 | 12 | 6.5 | 27.6 | ||||||
| RV2-8 | 11 | 12 | 8.4 | 27.6 | ||||||
| RV2-10 | 13.9 | 13.6 | 10.5 | 30.2 | ||||||
| RV3.5-4 | 14-12 | 2.5-4 | 6.3 | 12.5 | 7.7 | 8 | 4.3 | 24.5 | Black | 37 |
| RV3.5-5S | 7.7 | 8 | 5.3 | 24.5 | ||||||
| RV3.5-5L | 7.7 | 12 | 5.3 | 28 | ||||||
| RV3.5-6 | 7.7 | 12 | 6.5 | 28 | ||||||
| RV5.5-3.5 | 12-10 | 4-6 | 6.7 | 12.5 | 5.9 | 7.2 | 3.7 | 21.4 | Yellow | 48 |
| RV5.5-4S | 5.9 | 7.2 | 4.3 | 21.4 | ||||||
| RV5.5-4L | 8.3 | 9.5 | 4.3 | 25.5 | ||||||
| RV5.5-5 | 8.3 | 9.5 | 5.3 | 25.5 | ||||||
| RV5.5-6 | 13 | 12 | 6.5 | 31.5 | ||||||
| RV5.5-8 | 13.7 | 15 | 8.4 | 33.7 | ||||||
| RV5.5-10 | 13.7 | 15 | 10.5 | 33.7 | ||||||
| RV5.5-12 | 16 | 19.2 | 13 | 38.1 | ||||||
