PG Thread Cable Glands
PG glands for shielded cables - tighten to maintain electromagnetic integrity.
PG Thread Cable Glands are specified wherever shielded cables pass through an enclosure wall and electromagnetic integrity has to survive the journey. The Nylon 66 body and tight rubber ring let you clamp the screen at the gland, maintaining the shield bond simply by tightening the gland.
The PG series covers the classic PG07 up to the larger PG sizes, giving you the fitting your shielded cable run was designed around - and the reliable, professional entry that keeps EMC performance intact.
UL94V-2 certified, black or white, 100 pieces per pack or custom packaging for production programs.
Key Features
- Designed for shielded cables and EMC-sensitive applications
- Tightening the gland maintains the screen bond
- PG07 and larger PG sizes for standard fitting compatibility
- UL94V-2 Nylon 66 with rubber sealing ring
- Black or white; 100 pcs/pack or custom packaging
Applications
EMC-sensitive equipment, shielded cable installations, industrial electronics and any screened wiring entry into enclosures.
Specifications
| ITEM NO | L1 | Cable Range | L | Spanne Size | L2 |
|---|---|---|---|---|---|
| MM | MM | MM | MM | MM | |
| HS-PG07 | 8 | 3-6.5 | 22 | 16 | 12 |
| HS-PG09 | 8 | 4-8 | 26 | 19 | 16 |
| HS-PG11 | 8 | 5-10 | 27 | 22 | 18 |
| HS-PG13.5 | 9 | 6-12 | 28 | 24 | 20 |
| HS-PG16 | 10 | 10-14 | 30 | 27 | 22 |
| HS-PG19 | 10 | 12-15 | 30 | 27/28 | 24 |
| HS-PG21 | 10 | 13-18 | 35 | 33 | 28 |
| HS-PG25 | 11 | 16-21 | 34 | 35/36 | 30 |
| HS-PG29 | 12 | 18-25 | 40 | 41/42 | 37 |
| HS-PG36 | 14 | 22-32 | 48 | 52/53 | 47 |
| HS-PG42 | 14 | 32-38 | 49 | 60/61 | 54 |
| HS-PG48 | 14 | 37-44 | 50 | 64/65 | 59 |
| HS-PG63 | 27 | 42-50 | 60 | 72 | 70 |
